Prism is a multidimensional signal processor that creates a framework for the spectral metamorphosis of any input signal. This stereo audio buffer can be navigated through on 3 axes, each of which provides a different sonic journey through its array of time based controls.
Features
- Multidimensional signal processor
- Stereo inputs and outputs
- Flexible delay line providing long delays, and comb filtering
- Bit depth and sample rate manipulation
- State variable filter with LPF, HPF, and BPF
- Freeze control locks buffer in place for glitch and beat repeat effects
- Aluminum front panel
Specifications
Width: 12 hp
Depth: 22 mm
Power: +12V: 90mA, -12V: 10mA
