Neuzeit Instruments Warp Eurorack Wavetable Synth Voice Module

Warp is a synthesizer with a novel hybrid engine that combines the best of additive and wavetable synthesis. It is a feature-rich powerhouse that lets you create all kinds of sounds, from glassy clean to crunchy crunch. Thanks to expressive macro tone controls, extreme morphs are possible in a single pot turn. With the integrated editor you can playfully draw your own overtone spectra into the colorful XY matrix and also export them as wavetables for other synths.

Features

• Complete synthesizer with 4 voices and 2 oscillators each
• Innovative hybrid of additive and wavetable synthesis
• Four voice polyphonic with WarpEx Expander, monophonic as standalone unit
• MPE and MIDI capable with WarpEx Expander, but also playable polyphonic with 4x CV & Gate
• Comes factory equipped with numerous Factory- and Artist-Created features
• Large pots act as performance-oriented macro controls for several internal parameters
• Each pot has its own CV input
• Graphically appealing, animated and easy to follow menu
• Internal modulation: 2x ADSR, Note-Key and 2x LFO with a variety of waveforms
• External modulation: OMNI CV input (24-bit), MIDI velocity, MIDI aftertouch, MIDI CC
• Powerful and clearly animated modulation matrix with 8 x 19 = 152 internal modulation values per voice
• Many modulation destinations can be modulated at up to 24kHz, a unique feature in digital synthesizers
• The XY matrix serves as a pool of 32 x 16 overtone spectra from which each voice draws its basic sound
• X and Y position to scan overtone spectra in two dimensions (with interpolation), as in wavetable synths
• Complex spectral filter is applied to overtone spectrum before wavetable is calculated in real time
• A mix of wavetable effects changes the waveform in the time domain: Fold, Drive, Bend and Redux
• The waveform is used by two oscillators per voice, which can interact through several effects
• Oscillator effects: Linear detune, Sync, AM, FM, Phase distortion, filtered noise.
• Low-pass and high-pass filters with 12 or 24dB per octave as well as filter resonance
• Two outputs for stereo or two signal busses. 24 bit, 48kHz output, 32 bit internal
• Pitch adjustment with stepped encoder in octaves, semitones or fine tuning. Quick reset on long-press
• Several intuitive editors on board to draw your own overtone spectra or derive them from audio files
• Wavetable export function to create wavetable files in the appropriate target format for other synthesizers

Specifications
Width: 24hp
Depth: 30mm
Power: +225mA, -25mA

Manufacturer product page here.
Product manual here.
