Elektron Octatrack MKII Desktop Sampler and Sequencer

With the Octatrack MKII, discovering the perfect sample is only the beginning. Twist it, dismantle it, distort it, and carve it into something uniquely yours.

The Octatrack MKII redefines how you transform your sounds, as well as how you interact and play with them.

This sorcerer’s box brings enormous sample processing ability to the table, offering deep and radical manipulation of samples and loops in both rapid and improvisational live performance, and meticulous composition.

Record samples in real time via any of the Octatrack’s varied source options. Connect directly to the four inputs, resample an internal track, or pull on the main and cue channels.

Then trim, time-stretch, and pitch-shift your audio nuggets into the perfectly sized loops, one shots, or slices for your composition. And do it all live.

The powerful crossfader adds immense depth of control. Choose how you want it to affect your samples. Then decide how you want to wield it. Set up assignable scenes to each side of the crossfader. Toggle between them, or morph from A to B.

Nudge gently for subtle, natural-sounding transitions or knock it back and forth for extreme, unexpected changes.

The Octrack MKII is a machine with enormous sound design capabilities. With three LFOs available for each track, as well as a LFO designer, there are deeply customizable wave-weaving possibilities at your disposal.

You can also assign two insert effects per audio track, offering a vast selection of reverbs, filters, phasers, and plenty more to play with. Utter audio manipulation has rarely been so varied or so much fun.

The Octatrack MKII can be treated as a small mixing desk for your whole setup, making use of the unit’s configurable two stereo inputs, and main, cue, and headphone outputs. Then connect external MIDI gear and let the machine orchestrate proceedings via dedicated tracks. The immediate control makes all the difference.

And with the game-changing Elektron sequencer, you can lay your ideas out with absolute control and ambition unlocking depth. Command both internal sounds and external gear with the same level of razor-sharp precision.

Specifications

Audio track features (×8)

• 1 × Specialized machine
• 1 × Track recorder
• 1 × Amplitude envelope
• 3 × LFOs
• 2 × User selectable track effects

MIDI track features (×8)

• 1 × Arpeggiator
• 3 × LFOs
• 10 × configurable CCs

Sequencer

• 8 × Audio tracks
• 8 × MIDI tracks
• Up to 64 steps per pattern
• Individual track lengths
• Individual track time signatures
• Chromatic, slice, slot, and delay freeze modes
• Parameter locks
• Trig conditions
• Tempo Per Pattern
• Trig Preview
• Sample-per-step change
• Micro timing
• Retrig functionality
• Swing and slide
• Full real-time control

Storage

• CompactFlash card storage
• Amount of Projects dependent on CF card size
• 80 MB Flex RAM per project
• Static sample streaming from CF card
• 256 patterns per Project
• 256 sample slots per Project
• 8 Arrangements per Project

Track effects

• 12/24dB multi mode filter
• 2-band parametric EQ
• DJ-style kill EQ
• 2-10 stage phaser
• Flanger
• 2-5 tap chorus
• Spatializer
• Comb filter
• Compressor
• Lo-Fi (SRR, BR, Dist and AM)
• Echo freeze delay
• Gatebox plate reverb
• Spring reverb
• Dark reverb

Hardware

• 128 × 64 pixel OLED screen
• MIDI In/Out/Thru
• 2 × 1/4” impedance balanced main audio out jacks
• 2 × 1/4” impedance balanced cue audio out jacks
• 4 × 1/4” balanced/unbalanced external input jacks
• 1 × 1/4” stereo headphone jack
• 44.1 kHz, 24-bit D/A and A/D converters
• Hi-speed USB 2.0 port
• Power inlet: Center positive 5.5 × 2.5 mm barrel jack, 12 V DC, 2 A

Balanced audio outputs

• Main outputs level: +17 dBu peak
• Output impedance: 440 ? unbalanced
• Digital S/N ratio: 104 dB (20–20,000 Hz)

Headphones outputs

• Headphones out level: +17 dBu peak
• Output impedance: 55 ?

Balanced audio inputs

• Input level: +17 dBu peak
• Audio input impedance: 21 k?
• Digital S/N ratio: 106 dB (20–20,000 Hz)

Electrical specifications

• Unit power consumption: 7 W typical
• Compatible Elektron power supply: PSU-3c & PSU-3b

Physical specifications

• Sturdy steel casing
• Dimensions: W 340 × D 184 × H 63 mm (13.3” × 7.2” × 2.5”) (including knobs, jacks, and rubber feet)
• Weight: approximately 2.3 kg (5 lbs)
• Maximum recommended ambient operating temperature: +40?C (+104?F)

Miscellaneous

• 4.9 GB of high-quality samples on the CF card
• 3 year Elektron warranty

Included in the box

• 32 GB high speed CompactFlash card
• Power Supply PSU-3c
• Elektron USB cable
• Quick Guide
