4ms Pingable Envelope Generator Eurorack Module is a dual envelope generator whose envelope lengths are set by incoming clocks or “pings”.
The PEG has full CV control of envelope shape, skew, and ping (clock) division/multiplication, as well as a plethora of triggering and cycling options (AD, AR, quantization, cycle), and a tap tempo button for each channel.
Basics:
- Dual “pingable” envelope generator’s total envelope time is set by a “ping”
- Tap tempo button or incoming clock sets the ping time
- Envelope time is a multiple or division of the ping time (from /8 to x8) set by Ping Div/Mult knob and CV
- Curve knob and CV control the shape of the output envelope. Various combinations of exponential, linear, logarithmic, and interpolated curves are available for the rise and fall portions. Total envelope time is maintained throughout any curve selection.
- Skew knob and CV control the ratio between rise and fall times without changing total envelope time
Specifications
Width: 12hp
Depth: 25mm
Power: 44 mA +12V, 30 mA -12V, 0 mA 5V
